H Vertebra
Home Up Location Diagnosis
Back Next



Atlas of Signs in Musculoskeletal Radiology is approved by the ARRS (American Roentgen Ray Society) and is included in AJR Webreview
A. Gentili,MD, M. Beller, MD, S. Masih, MD, L.L. Seeger, MD

Diagnosis:

Sickle cell anemia

Discussion:

Lateral radiographs of the spine reveals central endplate depression with sparing of the anterior and posterior margins of the endplate. Several current names have been ascribed to these same changes seen in patients with hemoglobinopathy, such as Lincoln Log Sign, or H-shaped vertebra. Although not pathognomonic, these terms are typically reserved for a patient with Sickle-Cell disease.


 - Click on the image for a larger version

References:

bulletHansen GC, Gold RH: Central depression of multiple vertebral end-plates: a "pathognomonic" sign of sickle hemoglobinopathy in Gaucher's disease AJR Am J Roentgenol 1977 Aug;129(2):343-4.          [See related articles]
