Inverted Napoleon Hat Sign
Home Up Location Diagnosis
Back Next



Atlas of Signs in Musculoskeletal Radiology is approved by the ARRS (American Roentgen Ray Society) and is included in AJR Webreview
A. Gentili,MD, M. Beller, MD, S. Masih, MD, L.L. Seeger, MD

Diagnosis:

Spondylolisthesis

Discussion:

Frontal and lateral radiographs of the lumbar spine revealing anterolisthesis of the L5 vertebral body with the typical inverted Napoleon Hat sign. This sign is reserved for spondylolisthesis of the L5 vertebral body. With a case of spondylolisthesis, the AP radiograph will reveal the anterior border of the transverse process in continuity with the anterior border of the body of the same vertebrae. This continuous anterior border of the L5 vertebrae will be projected against the shadow of the sacrum, and appear as an upside-down (or inverted) Napoleon hat.


Lateral Lumbar Spine - Click on the image for a larger versionAAP L-S spine - Click on the image for a larger versionB

References:

bulletGarland LH, Thomas SF: Spondylolisthesis. Am J Roentgenol1946, 55: 275-91.
